1WCG

Aphid myrosinase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.10 Å
  • R-Value Free: 0.146
  • R-Value Work: 0.132
  • R-Value Observed: 0.133

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Crystal Structure at 1.1A Resolution of an Insect Myrosinase from Brevicoryne Brassicae Shows its Close Relationship to Beta-Glucosidases.

Husebye, H.Arzt, S.Burmeister, W.P.Haertel, F.V.Brandt, A.Rossiter, J.T.Bones, A.M.

(2005) Insect Biochem Mol Biol 35: 1311

  • DOI: https://doi.org/10.1016/j.ibmb.2005.07.004
  • Primary Citation of Related Structures:
    1WCG

  • PubMed Abstract:

    The aphid Brevicoryne brassicae is a specialist feeding on Brassicaceae plants. The insect has an intricate defence system involving a beta-D-thioglucosidase (myrosinase) that hydrolyses glucosinolates sequestered from the host plant into volatile isothiocyanates. These isothiocyanates act synergistically with the pheromone E-beta-farnesene to form an alarm system when the aphid is predated. In order to investigate the enzymatic characteristics of the aphid myrosinase and its three-dimensional structure, milligram amounts of pure recombinant aphid myrosinase were obtained from Echerichia coli. The recombinant enzyme had similar physiochemical properties to the native enzyme. The global structure is very similar to Sinapis alba myrosinase and plant beta-O-glucosidases. Aphid myrosinase has two catalytic glutamic acid residues positioned as in plant beta-O-glucosidases, and it is not obvious why this unusual enzyme hydrolyses glucosinolates, the common substrates of plant myrosinases which are normally not hydrolyzed by plant beta-O-glucosidases. The only residue specific for aphid myrosinase in proximity of the glycosidic linkage is Tyr180 which may have a catalytic role. The aglycon binding site differs strongly from plant myrosinase, whereas due to the presence of Trp424 in the glucose binding site, this part of the active site is more similar to plant beta-O-glucosidases, as plant myrosinases carry a phenylalanine residue at this position.


  • Organizational Affiliation

    Department of Biology, Norwegian University of Science and Technology, Trondheim.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
THIOGLUCOSIDASE
A, B
464Brevicoryne brassicaeMutation(s): 0
EC: 3.2.3.1 (PDB Primary Data), 3.2.1.147 (UniProt)
UniProt
Find proteins for Q95X01 (Brevicoryne brassicae)
Explore Q95X01
Go to UniProtKB:  Q95X01
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ95X01
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.10 Å
  • R-Value Free: 0.146
  • R-Value Work: 0.132
  • R-Value Observed: 0.133
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 73.853α = 90
b = 67.365β = 93.7
c = 97.301γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
MOSFLMdata reduction
SCALAdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2005-11-23
    Type: Initial release
  • Version 1.1: 2011-05-08
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2019-05-08
    Changes: Data collection, Experimental preparation, Other
  • Version 1.4: 2023-12-13
    Changes: Data collection, Database references, Other, Refinement description
