5WLI

Crystal Structure of H-2Db with the GAP501 peptide (SQL)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.209
  • R-Value Observed: 0.211

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

A T Cell Receptor Locus Harbors a Malaria-Specific Immune Response Gene.

Van Braeckel-Budimir, N.Gras, S.Ladell, K.Josephs, T.M.Pewe, L.Urban, S.L.Miners, K.L.Farenc, C.Price, D.A.Rossjohn, J.Harty, J.T.

(2017) Immunity 47: 835-847.e4

  • DOI: https://doi.org/10.1016/j.immuni.2017.10.013
  • Primary Citation of Related Structures:
    5WLG, 5WLI

  • PubMed Abstract:

    Immune response (Ir) genes, originally proposed by Baruj Benacerraf to explain differential antigen-specific responses in animal models, have become synonymous with the major histocompatibility complex (MHC). We discovered a non-MHC-linked Ir gene in a T cell receptor (TCR) locus that was required for CD8 + T cell responses to the Plasmodium berghei GAP50 40-48 epitope in mice expressing the MHC class I allele H-2D b . GAP50 40-48 -specific CD8 + T cell responses emerged from a very large pool of naive Vβ8.1 + precursors, which dictated susceptibility to cerebral malaria and conferred protection against recombinant Listeria monocytogenes infection. Structural analysis of a prototypical Vβ8.1 + TCR-H-2D b -GAP50 40-48 ternary complex revealed that germline-encoded complementarity-determining region 1β residues present exclusively in the Vβ8.1 segment mediated essential interactions with the GAP50 40-48 peptide. Collectively, these findings demonstrated that Vβ8.1 functioned as an Ir gene that was indispensable for immune reactivity against the malaria GAP50 40-48 epitope.


  • Organizational Affiliation

    Department of Microbiology, University of Iowa, Iowa City, IA 52242, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
H-2 class I histocompatibility antigen, D-B alpha chain
A, D, G, J
278Mus musculusMutation(s): 0
Gene Names: H2-D1
UniProt
Find proteins for P01899 (Mus musculus)
Explore P01899
Go to UniProtKB:  P01899
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01899
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Beta-2-microglobulin
B, E, H, K
99Mus musculusMutation(s): 0
Gene Names: B2m
UniProt & NIH Common Fund Data Resources
Find proteins for P01887 (Mus musculus)
Explore P01887
Go to UniProtKB:  P01887
IMPC:  MGI:88127
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01887
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
GAP50 peptide
C, F, I, L
9Plasmodium bergheiMutation(s): 0
UniProt
Find proteins for A0A0Y9W4B5 (Plasmodium berghei)
Explore A0A0Y9W4B5
Go to UniProtKB:  A0A0Y9W4B5
Entity Groups
UniProt GroupA0A0Y9W4B5
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.209
  • R-Value Observed: 0.211
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 53.271α = 90
b = 159.924β = 92.33
c = 108.461γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
Aimlessdata scaling
PHASERphasing
PDB_EXTRACTdata extraction
XDSdata processing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-11-15
    Type: Initial release
  • Version 1.1: 2018-11-28
    Changes: Data collection, Database references, Source and taxonomy, Structure summary
  • Version 1.2: 2019-05-29
    Changes: Data collection, Database references
