6RHQ

Crystal Structure of Two-Domain Laccase mutant I170A from Streptomyces griseoflavus


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.98 Å
  • R-Value Free: 0.215
  • R-Value Work: 0.174
  • R-Value Observed: 0.176

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Investigations of Accessibility of T2/T3 Copper Center of Two-Domain Laccase fromStreptomyces griseoflavusAc-993.

Gabdulkhakov, A.Kolyadenko, I.Kostareva, O.Mikhaylina, A.Oliveira, P.Tamagnini, P.Lisov, A.Tishchenko, S.

(2019) Int J Mol Sci 20

  • DOI: https://doi.org/10.3390/ijms20133184
  • Primary Citation of Related Structures:
    5MKM, 6FC7, 6FDJ, 6RH9, 6RHQ, 6S0O

  • PubMed Abstract:

    Laccases (EC 1.10.3.2) are multicopper oxidoreductases acting on diphenols and related substances. Laccases are highly important for biotechnology and environmental remediation. These enzymes contain mononuclear one T2 copper ion and two T3 copper ions (Cu3 α and Cu3 β ), which form the so-called trinuclear center (TNC). Along with the typical three-domain laccases Bacteria produce two-domain (2D) enzymes, which are active at neutral and basic pH, thermostable, and resistant to inhibitors. In this work we present the comparative analysis of crystal structures and catalytic properties of recombinant 2D laccase from Streptomyces griseoflavus Ac-993 (SgfSL) and its four mutant forms with replacements of two amino acid residues, located at the narrowing of the presumable T3-solvent tunnels. We obtained inactive enzymes with substitutions of His165, with Phe, and Ile170 with Ala or Phe. His165Ala variant was more active than the wild type. We suggest that His165 is a "gateway" at the O 2 -tunnel leading from solvent to the Cu3 β of the enzyme. The side chain of Ile170 could be indirectly involved in the coordination of copper ions at the T3 center by maintaining the position of the imidazole ring of His157 that belongs to the first coordination sphere of Cu3 α .


  • Organizational Affiliation

    Institute of Protein Research RAS, Institutskaya 4, Pushchino, Moscow 142290, Russia.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Two-domain laccase
A, B, C, D, E
A, B, C, D, E, F
322Streptomyces griseoflavusMutation(s): 1
EC: 1.10.3.2
UniProt
Find proteins for A0A0M4FJ81 (Streptomyces griseoflavus)
Explore A0A0M4FJ81
Go to UniProtKB:  A0A0M4FJ81
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0M4FJ81
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download Ideal Coordinates CCD File
BA [auth E],
HA [auth F]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL
Query on GOL

Download Ideal Coordinates CCD File
CA [auth E],
W [auth D]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CU
Query on CU

Download Ideal Coordinates CCD File
AA [auth E]
DA [auth F]
EA [auth F]
FA [auth F]
G [auth A]
AA [auth E],
DA [auth F],
EA [auth F],
FA [auth F],
G [auth A],
GA [auth F],
H [auth A],
I [auth A],
J [auth A],
K [auth B],
L [auth B],
M [auth B],
N [auth B],
O [auth C],
P [auth C],
Q [auth C],
R [auth C],
S [auth D],
T [auth D],
U [auth D],
V [auth D],
X [auth E],
Y [auth E],
Z [auth E]
COPPER (II) ION
Cu
JPVYNHNXODAKFH-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.98 Å
  • R-Value Free: 0.215
  • R-Value Work: 0.174
  • R-Value Observed: 0.176
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 74.79α = 90
b = 94.69β = 90.87
c = 116.49γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Russian Foundation for Basic ResearchRussian Federation18-04-00270a

Revision History  (Full details and data files)

  • Version 1.0: 2019-07-17
    Type: Initial release
  • Version 1.1: 2024-01-24
    Changes: Data collection, Database references, Derived calculations, Refinement description
