8HB9

Crystal Structure of Human IDH1 R132H Mutant in Complex with NADPH and Compound IHMT-IDH1-053


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.243
  • R-Value Work: 0.216

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Structure-based discovery of IHMT-IDH1-053 as a potent irreversible IDH1 mutant selective inhibitor.

Liang, Q.Wang, B.Zou, F.Guo, G.Wang, W.Wang, W.Liu, Q.Shen, L.Hu, C.Wang, W.Wang, A.Huang, T.He, Y.Xia, R.Ge, J.Liu, J.Liu, Q.

(2023) Eur J Med Chem 256: 115411-115411

  • DOI: https://doi.org/10.1016/j.ejmech.2023.115411
  • Primary Citation of Related Structures:
    8HB9

  • PubMed Abstract:

    Through a structure-based irreversible drug design approach, we have discovered a highly potent IDH1-mutant inhibitor compound 16 (IHMT-IDH1-053) (IC 50  = 4.7 nM), which displays high selectivity against IDH1 mutants over IDH1 wt and IDH2 wt/mutants. The crystal structure demonstrates that 16 binds to the IDH1 R132H protein in the allosteric pocket adjacent to the NAPDH binding pocket through a covalent bond with residue Cys269. 16 inhibits 2-hydroxyglutarate (2-HG) production in IDH1 R132H mutant transfected 293T cells (IC 50  = 28 nM). In addition, it inhibits the proliferation of HT1080 cell line and primary AML cells which both bear IDH1 R132 mutants. In vivo, 16 inhibits 2-HG level in a HT1080 xenograft mouse model. Our study suggested that 16 would be a new pharmacological tool to study IDH1 mutant-related pathology and the covalent binding mode provided a novel approach for designing irreversible IDH1 inhibitors.


  • Organizational Affiliation

    Anhui Province Key Laboratory of Medical Physics and Technology, Institute of Health and Medical Technology, Hefei Institutes of Physical Science, Chinese Academy of Sciences, Hefei, Anhui, 230031, PR China; University of Science and Technology of China, Hefei, Anhui, 230026, PR China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Isocitrate dehydrogenase [NADP] cytoplasmicA [auth AAA],
B [auth BBB],
C [auth CCC],
D [auth DDD]
414Homo sapiensMutation(s): 1
Gene Names: IDH1PICD
EC: 1.1.1.42
UniProt & NIH Common Fund Data Resources
Find proteins for O75874 (Homo sapiens)
Explore O75874
Go to UniProtKB:  O75874
PHAROS:  O75874
GTEx:  ENSG00000138413
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO75874
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NDP (Subject of Investigation/LOI)
Query on NDP

Download Ideal Coordinates CCD File
F [auth AAA],
P [auth BBB],
S [auth CCC],
V [auth DDD]
NADPH DIHYDRO-NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE
C21 H30 N7 O17 P3
ACFIXJIJDZMPPO-NNYOXOHSSA-N
R1R (Subject of Investigation/LOI)
Query on R1R

Download Ideal Coordinates CCD File
E [auth AAA],
O [auth BBB],
R [auth CCC],
U [auth DDD]
[2-[2-[[1-[4-[(1S)-1-[[5-fluoranyl-4-[(4S)-2-oxidanylidene-4-propan-2-yl-1,3-oxazolidin-3-yl]pyrimidin-2-yl]amino]ethyl]phenyl]piperidin-4-yl]sulfamoyl]ethylsulfanylmethyl]-3-oxidanylidene-propyl]-trimethyl-azanium
C32 H49 F N7 O5 S2
LCIIBZXZTLMNNC-QFTSJRPJSA-N
PEG
Query on PEG

Download Ideal Coordinates CCD File
I [auth AAA],
J [auth AAA],
M [auth AAA],
N [auth AAA],
X [auth DDD]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
G [auth AAA]
H [auth AAA]
K [auth AAA]
L [auth AAA]
Q [auth BBB]
G [auth AAA],
H [auth AAA],
K [auth AAA],
L [auth AAA],
Q [auth BBB],
T [auth CCC],
W [auth DDD]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.243
  • R-Value Work: 0.216
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 84.759α = 90
b = 76.426β = 98.27
c = 171.971γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
CrysalisProdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China81703007
National Natural Science Foundation of China (NSFC)China81603123
National Natural Science Foundation of China (NSFC)China81673469
National Natural Science Foundation of China (NSFC)China81773777
National Natural Science Foundation of China (NSFC)China81872748
National Natural Science Foundation of China (NSFC)China81803366

Revision History  (Full details and data files)

  • Version 1.0: 2023-05-24
    Type: Initial release
  • Version 1.1: 2023-05-31
    Changes: Database references
  • Version 1.2: 2024-02-07
    Changes: Data collection, Refinement description
  • Version 1.3: 2024-11-06
    Changes: Structure summary
