9XAQ | pdb_00009xaq

Cryatal structure of apo-state RhoBAST-G38U

• PDB DOI: https://doi.org/10.2210/pdb9XAQ/pdb

• Classification: RNA
• Organism(s): synthetic construct
• Expression System: in vitro transcription vector pT7-TP(deltai)
• Mutation(s): No


• Deposited: 2025-10-22 Released: 2026-10-28
• Deposition Author(s): Tai, X.Q., Ren, A.M.
• Funding Organization(s): National Natural Science Foundation of China (NSFC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free:
  0.247 (Depositor), 0.247 (DCC)
• R-Value Work:
  0.203 (Depositor), 0.202 (DCC)
• R-Value Observed:
  0.207 (Depositor)

Starting Model: experimental

Literature

Cryatal structure of apo-state RhoBAST-G38U

Tai, X.Q., Ren, A.M.

To be published.

Biological Assembly 1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 18.64 kDa
• Atom Count: 1,236
• Modeled Residue Count: 57
• Deposited Residue Count: 57
• Unique nucleic acid chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Length	Organism	Image
RNA (57-MER)	A [auth U]	57	synthetic construct

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MG	B [auth U]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free:  0.247 (Depositor), 0.247 (DCC)
• R-Value Work:  0.203 (Depositor), 0.202 (DCC)
• R-Value Observed: 0.207 (Depositor)

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 81.405	α = 90
b = 81.405	β = 90
c = 98.722	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data scaling
PDB_EXTRACT	data extraction
HKL-3000	data reduction
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2026-10-28
Deposition Author(s): Tai, X.Q., Ren, A.M.

---

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History

• Version 1.0: 2026-10-28
  Type: Initial release
