2FPE

Conserved dimerization of the ib1 src-homology 3 domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free: 0.235
  • R-Value Work: 0.204
  • R-Value Observed: 0.204

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.6 of the entry. See complete history


Literature

A unique set of SH3-SH3 interactions controls IB1 homodimerization

Kristensen, O.Guenat, S.Dar, I.Allaman-Pillet, N.Abderrahmani, A.Ferdaoussi, M.Roduit, R.Maurer, F.Beckmann, J.S.Kastrup, J.S.Gajhede, M.Bonny, C.

(2006) EMBO J 25: 785-797

  • DOI: https://doi.org/10.1038/sj.emboj.7600982
  • Primary Citation of Related Structures:
    2FPD, 2FPE, 2FPF

  • PubMed Abstract:

    Islet-brain 1 (IB1 or JIP-1) is a scaffold protein that interacts with components of the c-Jun N-terminal kinase (JNK) signal-transduction pathway. IB1 is expressed at high levels in neurons and in pancreatic beta-cells, where it controls expression of several insulin-secretory components and secretion. IB1 has been shown to homodimerize, but neither the molecular mechanisms nor the function of dimerization have yet been characterized. Here, we show that IB1 homodimerizes through a novel and unique set of Src homology 3 (SH3)-SH3 interactions. X-ray crystallography studies show that the dimer interface covers a region usually engaged in PxxP-mediated ligand recognition, even though the IB1 SH3 domain lacks this motif. The highly stable IB1 homodimer can be significantly destabilized in vitro by three individual point mutations directed against key residues involved in dimerization. Each mutation reduces IB1-dependent basal JNK activity in 293T cells. Impaired dimerization also results in a reduction in glucose transporter type 2 expression and in glucose-dependent insulin secretion in pancreatic beta-cells. Taken together, these results indicate that IB1 homodimerization through its SH3 domain has pleiotropic effects including regulation of the insulin secretion process.


  • Organizational Affiliation

    Biostructural Research, Department of Medicinal Chemistry, The Danish University of Pharmaceutical Sciences, Copenhagen, Denmark. ok@dfuni.dk


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
C-jun-amino-terminal kinase interacting protein 1
A, B, C, D, E
A, B, C, D, E, F, G, H
62Rattus norvegicusMutation(s): 0
Gene Names: Mapk8ip1Ib1Jip1
UniProt
Find proteins for Q9R237 (Rattus norvegicus)
Explore Q9R237
Go to UniProtKB:  Q9R237
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9R237
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
P6G
Query on P6G

Download Ideal Coordinates CCD File
K [auth A],
N [auth D],
R [auth G]
HEXAETHYLENE GLYCOL
C12 H26 O7
IIRDTKBZINWQAW-UHFFFAOYSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
I [auth A]
J [auth A]
L [auth B]
M [auth C]
O [auth E]
I [auth A],
J [auth A],
L [auth B],
M [auth C],
O [auth E],
P [auth E],
S [auth H]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
SO2
Query on SO2

Download Ideal Coordinates CCD File
Q [auth F]SULFUR DIOXIDE
O2 S
RAHZWNYVWXNFOC-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B, C, D, E
A, B, C, D, E, F, G, H
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free: 0.235
  • R-Value Work: 0.204
  • R-Value Observed: 0.204
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 75.594α = 90
b = 81.591β = 90
c = 89.733γ = 90
Software Package:
Software NamePurpose
MOSFLMdata reduction
SCALAdata scaling
TRUNCATEdata reduction
CNSrefinement
CCP4data scaling
TRUNCATEdata scaling
CNSphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-02-28
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-10-18
    Changes: Refinement description
  • Version 1.4: 2023-10-25
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.5: 2023-11-15
    Changes: Data collection
  • Version 1.6: 2024-10-16
    Changes: Structure summary
