3POH

Crystal structure of an endo-beta-N-acetylglucosaminidase (BT_3987) from BACTEROIDES THETAIOTAOMICRON VPI-5482 at 1.55 A resolution

PDB DOI: https://doi.org/10.2210/pdb3POH/pdb

Classification: HYDROLASE
Organism(s): Bacteroides thetaiotaomicron VPI-5482
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2010-11-22 Released: 2010-12-29
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.55 Å
R-Value Free: 0.164
R-Value Work: 0.136
R-Value Observed: 0.138

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of an endo-beta-N-acetylglucosaminidase (BT_3987) from BACTEROIDES THETAIOTAOMICRON VPI-5482 at 1.55 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 49.73 kDa
Atom Count: 4,235
Modelled Residue Count: 435
Deposited Residue Count: 451
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Endo-beta-N-acetylglucosaminidase F1	A	451	Bacteroides thetaiotaomicron VPI-5482	Mutation(s): 0 Gene Names: BT_3987
UniProt
Find proteins for Q8A0N4 (Bacteroides thetaiotaomicron (strain ATCC 29148 / DSM 2079 / JCM 5827 / CCUG 10774 / NCTC 10582 / VPI-5482 / E50)) Explore Q8A0N4 Go to UniProtKB: Q8A0N4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q8A0N4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
IMD Query on IMD Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	IMIDAZOLE C₃ H₅ N₂ RAXXELZNTBOGNW-UHFFFAOYSA-O		Interactions Focus chain B [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.55 Å
R-Value Free: 0.164
R-Value Work: 0.136
R-Value Observed: 0.138
Space Group: P 3₁ 2 1
Diffraction Data: https://doi.org/10.18430/M33POH

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 74.449	α = 90
b = 74.449	β = 90
c = 133.913	γ = 120

Software Package:

Software Name	Purpose
SHELX	phasing
REFMAC	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2010-12-29

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2010-12-29
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2011-07-20
Changes: Structure summary
Version 1.3: 2023-02-01
Changes: Database references, Derived calculations
