4BEN | pdb_00004ben

R39-imipenem Acyl-enzyme crystal structure

PDB DOI: https://doi.org/10.2210/pdb4BEN/pdb

Classification: HYDROLASE
Organism(s): Actinomadura sp. R39
Mutation(s): No

Deposited: 2013-03-11 Released: 2013-03-20
Deposition Author(s): Van Elder, D., Sauvage, E., Herman, R., Kerff, F., Rocaboy, M., Charlier, P.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.15 Å
R-Value Free:
0.234 (Depositor), 0.230 (DCC)
R-Value Work:
0.187 (Depositor), 0.190 (DCC)
R-Value Observed:
0.190 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Crystal Structures of R39-Imipenem Acyl-Enzyme.

Sauvage, E., Van Elder, D., Herman, R., Kerff, F., Pratt, R.F., Charlier, P.

To be published.

Macromolecule Content

Total Structure Weight: 195.44 kDa
Atom Count: 14,637
Modelled Residue Count: 1,864
Deposited Residue Count: 1,864
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
D-ALANYL-D-ALANINE CARBOXYPEPTIDASE	A, B, C, D	466	Actinomadura sp. R39	Mutation(s): 0 EC: 3.4.16.4
UniProt
Find proteins for P39045 (Actinomadura sp. (strain R39)) Explore P39045 Go to UniProtKB: P39045
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P39045
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
IM2 Query on IM2 Download Ideal Coordinates CCD File SDF format, chain CA [auth C] SDF format, chain E [auth A] SDF format, chain KA [auth D] SDF format, chain T [auth B] MOL2 format, chain CA [auth C] MOL2 format, chain E [auth A] MOL2 format, chain KA [auth D] MOL2 format, chain T [auth B] mmCIF format, chain CA [auth C] mmCIF format, chain E [auth A] mmCIF format, chain KA [auth D] mmCIF format, chain T [auth B]	CA [auth C], E [auth A], KA [auth D], T [auth B]	(5R)-5-[(1S,2R)-1-formyl-2-hydroxypropyl]-3-[(2-{[(E)-iminomethyl]amino}ethyl)sulfanyl]-4,5-dihydro-1H-pyrrole-2-carbox ylic acid C₁₂ H₁₉ N₃ O₄ S UACUABDJLSUFFC-IWSPIJDZSA-N		Interactions Focus chain CA [auth C] Focus chain E [auth A] Focus chain KA [auth D] Focus chain T [auth B] Interactions & Density Focus chain CA [auth C] Focus chain E [auth A] Focus chain KA [auth D] Focus chain T [auth B]
MES Query on MES Download Ideal Coordinates CCD File SDF format, chain VA [auth D] MOL2 format, chain VA [auth D] mmCIF format, chain VA [auth D]	VA [auth D]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C₆ H₁₃ N O₄ S SXGZJKUKBWWHRA-UHFFFAOYSA-N		Interactions Focus chain VA [auth D] Interactions & Density Focus chain VA [auth D]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain AA [auth B] SDF format, chain BA [auth B] SDF format, chain DA [auth C] SDF format, chain EA [auth C] SDF format, chain FA [auth C] SDF format, chain GA [auth C] SDF format, chain H [auth A] SDF format, chain HA [auth C] SDF format, chain I [auth A] SDF format, chain IA [auth C] SDF format, chain J [auth A] SDF format, chain JA [auth C] SDF format, chain K [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain NA [auth D] SDF format, chain O [auth A] SDF format, chain OA [auth D] SDF format, chain P [auth A] SDF format, chain PA [auth D] SDF format, chain Q [auth A] SDF format, chain QA [auth D] SDF format, chain R [auth A] SDF format, chain S [auth A] SDF format, chain SA [auth D] SDF format, chain TA [auth D] SDF format, chain U [auth B] SDF format, chain UA [auth D] SDF format, chain V [auth B] SDF format, chain W [auth B] SDF format, chain X [auth B] SDF format, chain Y [auth B] SDF format, chain Z [auth B] MOL2 format, chain AA [auth B] MOL2 format, chain BA [auth B] MOL2 format, chain DA [auth C] MOL2 format, chain EA [auth C] MOL2 format, chain FA [auth C] MOL2 format, chain GA [auth C] MOL2 format, chain H [auth A] MOL2 format, chain HA [auth C] MOL2 format, chain I [auth A] MOL2 format, chain IA [auth C] MOL2 format, chain J [auth A] MOL2 format, chain JA [auth C] MOL2 format, chain K [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain NA [auth D] MOL2 format, chain O [auth A] MOL2 format, chain OA [auth D] MOL2 format, chain P [auth A] MOL2 format, chain PA [auth D] MOL2 format, chain Q [auth A] MOL2 format, chain QA [auth D] MOL2 format, chain R [auth A] MOL2 format, chain S [auth A] MOL2 format, chain SA [auth D] MOL2 format, chain TA [auth D] MOL2 format, chain U [auth B] MOL2 format, chain UA [auth D] MOL2 format, chain V [auth B] MOL2 format, chain W [auth B] MOL2 format, chain X [auth B] MOL2 format, chain Y [auth B] MOL2 format, chain Z [auth B] mmCIF format, chain AA [auth B] mmCIF format, chain BA [auth B] mmCIF format, chain DA [auth C] mmCIF format, chain EA [auth C] mmCIF format, chain FA [auth C] mmCIF format, chain GA [auth C] mmCIF format, chain H [auth A] mmCIF format, chain HA [auth C] mmCIF format, chain I [auth A] mmCIF format, chain IA [auth C] mmCIF format, chain J [auth A] mmCIF format, chain JA [auth C] mmCIF format, chain K [auth A] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain NA [auth D] mmCIF format, chain O [auth A] mmCIF format, chain OA [auth D] mmCIF format, chain P [auth A] mmCIF format, chain PA [auth D] mmCIF format, chain Q [auth A] mmCIF format, chain QA [auth D] mmCIF format, chain R [auth A] mmCIF format, chain S [auth A] mmCIF format, chain SA [auth D] mmCIF format, chain TA [auth D] mmCIF format, chain U [auth B] mmCIF format, chain UA [auth D] mmCIF format, chain V [auth B] mmCIF format, chain W [auth B] mmCIF format, chain X [auth B] mmCIF format, chain Y [auth B] mmCIF format, chain Z [auth B]	AA [auth B] BA [auth B] DA [auth C] EA [auth C] FA [auth C] AA [auth B], BA [auth B], DA [auth C], EA [auth C], FA [auth C], GA [auth C], H [auth A], HA [auth C], I [auth A], IA [auth C], J [auth A], JA [auth C], K [auth A], M [auth A], N [auth A], NA [auth D], O [auth A], OA [auth D], P [auth A], PA [auth D], Q [auth A], QA [auth D], R [auth A], S [auth A], SA [auth D], TA [auth D], U [auth B], UA [auth D], V [auth B], W [auth B], X [auth B], Y [auth B], Z [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain AA [auth B] Focus chain BA [auth B] Focus chain DA [auth C] Focus chain EA [auth C] Focus chain FA [auth C] Focus chain GA [auth C] Focus chain H [auth A] Focus chain HA [auth C] Focus chain I [auth A] Focus chain IA [auth C] Focus chain J [auth A] Focus chain JA [auth C] Focus chain K [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain NA [auth D] Focus chain O [auth A] Focus chain OA [auth D] Focus chain P [auth A] Focus chain PA [auth D] Focus chain Q [auth A] Focus chain QA [auth D] Focus chain R [auth A] Focus chain S [auth A] Focus chain SA [auth D] Focus chain TA [auth D] Focus chain U [auth B] Focus chain UA [auth D] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B] Interactions & Density Focus chain AA [auth B] Focus chain BA [auth B] Focus chain DA [auth C] Focus chain EA [auth C] Focus chain FA [auth C] Focus chain GA [auth C] Focus chain H [auth A] Focus chain HA [auth C] Focus chain I [auth A] Focus chain IA [auth C] Focus chain J [auth A] Focus chain JA [auth C] Focus chain K [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain NA [auth D] Focus chain O [auth A] Focus chain OA [auth D] Focus chain P [auth A] Focus chain PA [auth D] Focus chain Q [auth A] Focus chain QA [auth D] Focus chain R [auth A] Focus chain S [auth A] Focus chain SA [auth D] Focus chain TA [auth D] Focus chain U [auth B] Focus chain UA [auth D] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain L [auth A] SDF format, chain RA [auth D] MOL2 format, chain L [auth A] MOL2 format, chain RA [auth D] mmCIF format, chain L [auth A] mmCIF format, chain RA [auth D]	L [auth A], RA [auth D]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain L [auth A] Focus chain RA [auth D] Interactions & Density Focus chain L [auth A] Focus chain RA [auth D]
MG Query on MG Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain LA [auth D] SDF format, chain MA [auth D] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain LA [auth D] MOL2 format, chain MA [auth D] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain LA [auth D] mmCIF format, chain MA [auth D]	F [auth A], G [auth A], LA [auth D], MA [auth D]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain LA [auth D] Focus chain MA [auth D] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain LA [auth D] Focus chain MA [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.15 Å
R-Value Free: 0.234 (Depositor), 0.230 (DCC)
R-Value Work: 0.187 (Depositor), 0.190 (DCC)
R-Value Observed: 0.190 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 103.623	α = 90
b = 91.911	β = 94.5
c = 106.924	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
MOSFLM	data reduction
SCALA	data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2013-03-20

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2013-03-20
Type: Initial release
Version 1.1: 2023-12-20
Changes: Data collection, Database references, Derived calculations, Other, Refinement description, Structure summary
Version 1.2: 2024-10-16
Changes: Structure summary
