4RBS

Crystal Structure of New Delhi Metallo-beta-Lactamase-1 in the Complex with Hydrolyzed Meropenem

PDB DOI: https://doi.org/10.2210/pdb4RBS/pdb

Classification: HYDROLASE
Organism(s): Klebsiella pneumoniae
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2014-09-12 Released: 2014-11-26
Deposition Author(s): Kim, Y., Tesar, C., Jedrzejczak, R., Babnigg, G., Sacchettini, J., Joachimiak, A., Midwest Center for Structural Genomics (MCSG), Structures of Mtb Proteins Conferring Susceptibility to Known Mtb Inhibitors (MTBI)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free: 0.207
R-Value Work: 0.174
R-Value Observed: 0.175

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of New Delhi Metallo-beta-Lactamase-1 in the Complex with Hydrolyzed Meropenem

Kim, Y., Tesar, C., Jedrzejczak, R., Babnigg, G., Sacchettini, J., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 53.01 kDa
Atom Count: 3,713
Modelled Residue Count: 472
Deposited Residue Count: 486
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-lactamase NDM-1	A, B	243	Klebsiella pneumoniae	Mutation(s): 0 Gene Names: blaNDM-1 EC: 3.5.2.6
UniProt
Find proteins for C7C422 (Klebsiella pneumoniae) Explore C7C422 Go to UniProtKB: C7C422
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	C7C422
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
0RV Query on 0RV Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain K [auth B] MOL2 format, chain E [auth A] MOL2 format, chain K [auth B] mmCIF format, chain E [auth A] mmCIF format, chain K [auth B]	E [auth A], K [auth B]	(2S)-2-[(1S,2R)-1-carboxy-2-hydroxypropyl]-4-{[(3S,5S)-5-(dimethylcarbamoyl)pyrrolidin-3-yl]sulfanyl}-3-methyl-2H-pyrro le-5-carboxylic acid C₁₇ H₂₅ N₃ O₆ S AGLQJULLKPLWOW-YBXAARCKSA-N		Interactions Focus chain E [auth A] Focus chain K [auth B] Interactions & Density Focus chain E [auth A] Focus chain K [auth B]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain N [auth B] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain N [auth B] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain N [auth B]	G [auth A], H [auth A], N [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain H [auth A] Focus chain N [auth B] Interactions & Density Focus chain G [auth A] Focus chain H [auth A] Focus chain N [auth B]
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain I [auth B] SDF format, chain J [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain I [auth B] MOL2 format, chain J [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain I [auth B] mmCIF format, chain J [auth B]	C [auth A], D [auth A], I [auth B], J [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain I [auth B] Focus chain J [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain I [auth B] Focus chain J [auth B]
ACY Query on ACY Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain L [auth B] SDF format, chain M [auth B] SDF format, chain O [auth B] MOL2 format, chain F [auth A] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] MOL2 format, chain O [auth B] mmCIF format, chain F [auth A] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B] mmCIF format, chain O [auth B]	F [auth A], L [auth B], M [auth B], O [auth B]	ACETIC ACID C₂ H₄ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain O [auth B] Interactions & Density Focus chain F [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain O [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free: 0.207
R-Value Work: 0.174
R-Value Observed: 0.175
Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 74.428	α = 90
b = 74.428	β = 90
c = 219.96	γ = 120

Software Package:

Software Name	Purpose
SBC-Collect	data collection
HKL-3000	data collection
HKL-3000	phasing
MOLREP	phasing
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2014-11-26

Deposition Author(s):

Midwest Center for Structural Genomics (MCSG)

Structures of Mtb Proteins Conferring Susceptibility to Known Mtb Inhibitors (MTBI)

Revision History (Full details and data files)

Version 1.0: 2014-11-26
Type: Initial release
Version 1.1: 2023-09-20
Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
