5CDO

3.15A structure of QPT-1 with S.aureus DNA gyrase and DNA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.15 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.215
  • R-Value Observed: 0.216

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Structural basis of DNA gyrase inhibition by antibacterial QPT-1, anticancer drug etoposide and moxifloxacin.

Chan, P.F.Srikannathasan, V.Huang, J.Cui, H.Fosberry, A.P.Gu, M.Hann, M.M.Hibbs, M.Homes, P.Ingraham, K.Pizzollo, J.Shen, C.Shillings, A.J.Spitzfaden, C.E.Tanner, R.Theobald, A.J.Stavenger, R.A.Bax, B.D.Gwynn, M.N.

(2015) Nat Commun 6: 10048-10048

  • DOI: https://doi.org/10.1038/ncomms10048
  • Primary Citation of Related Structures:
    5CDM, 5CDN, 5CDO, 5CDP, 5CDQ, 5CDR

  • PubMed Abstract:

    New antibacterials are needed to tackle antibiotic-resistant bacteria. Type IIA topoisomerases (topo2As), the targets of fluoroquinolones, regulate DNA topology by creating transient double-strand DNA breaks. Here we report the first co-crystal structures of the antibacterial QPT-1 and the anticancer drug etoposide with Staphylococcus aureus DNA gyrase, showing binding at the same sites in the cleaved DNA as the fluoroquinolone moxifloxacin. Unlike moxifloxacin, QPT-1 and etoposide interact with conserved GyrB TOPRIM residues rationalizing why QPT-1 can overcome fluoroquinolone resistance. Our data show etoposide's antibacterial activity is due to DNA gyrase inhibition and suggests other anticancer agents act similarly. Analysis of multiple DNA gyrase co-crystal structures, including asymmetric cleavage complexes, led to a 'pair of swing-doors' hypothesis in which the movement of one DNA segment regulates cleavage and religation of the second DNA duplex. This mechanism can explain QPT-1's bacterial specificity. Structure-based strategies for developing topo2A antibacterials are suggested.


  • Organizational Affiliation

    Antibacterial Discovery Performance Unit, Infectious Diseases, Therapy Area Unit, GlaxoSmithKline, 1250 South Collegeville Road, Collegeville, Pennsylvania 19426-0989, USA.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA gyrase subunit AA,
C,
G [auth R],
I [auth T]
482Staphylococcus aureus subsp. aureus N315Mutation(s): 0
Gene Names: gyrASA0006
EC: 5.99.1.3 (PDB Primary Data), 5.6.2.2 (UniProt)
UniProt
Find proteins for Q99XG5 (Staphylococcus aureus (strain N315))
Explore Q99XG5
Go to UniProtKB:  Q99XG5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ99XG5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA gyrase subunit B,DNA gyrase subunit BB,
D,
H [auth S],
J [auth U]
188Staphylococcus aureus subsp. aureus N315Mutation(s): 0
Gene Names: gyrBSA0005
EC: 5.99.1.3 (PDB Primary Data), 5.6.2.2 (UniProt)
UniProt
Find proteins for P66937 (Staphylococcus aureus (strain N315))
Explore P66937
Go to UniProtKB:  P66937
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP66937
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains LengthOrganismImage
DNA (5'-D(P*GP*AP*GP*CP*GP*TP*AP*C*GP*GP*CP*CP*GP*TP*AP*CP*GP*CP*TP*T)-3')E,
F,
K [auth V],
L [auth W]
20synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 7 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
50M
Query on 50M

Download Ideal Coordinates CCD File
Z [auth S](2R,4S,4aS,5R)-6'-hydroxy-2,4-dimethyl-8-nitro-1,2,4,4a-tetrahydro-2'H,6H-spiro[1,4-oxazino[4,3-a]quinoline-5,5'-pyrimidine]-2',4'(3'H)-dione
C17 H18 N4 O6
DJZPHYIXNUOVJU-VYUIOLGVSA-N
53L
Query on 53L

Download Ideal Coordinates CCD File
W [auth F](2R,4S,4aS,5S)-6'-hydroxy-2,4-dimethyl-8-nitro-1,2,4,4a-tetrahydro-2'H,6H-spiro[1,4-oxazino[4,3-a]quinoline-5,5'-pyrimidine]-2',4'(3'H)-dione
C17 H18 N4 O6
DJZPHYIXNUOVJU-VYUIOLGVSA-N
53M
Query on 53M

Download Ideal Coordinates CCD File
GA [auth W],
V [auth E]
(2R,4S,4aS)-4',6'-dihydroxy-2,4-dimethyl-8-nitro-1,2,4,4a-tetrahydro-2'H,6H-spiro[1,4-oxazino[4,3-a]quinoline-5,5'-pyrimidin]-2'-one
C17 H18 N4 O6
DJZPHYIXNUOVJU-VYUIOLGVSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
AA [auth T],
BA [auth T],
M [auth A]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL
Query on GOL

Download Ideal Coordinates CCD File
EA [auth U],
FA [auth U],
O [auth A],
T [auth D],
U [auth D]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
MN
Query on MN

Download Ideal Coordinates CCD File
DA [auth U],
P [auth B],
S [auth D],
Y [auth S]
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
NA
Query on NA

Download Ideal Coordinates CCD File
CA [auth T],
N [auth A],
Q [auth C],
R [auth C],
X [auth R]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
PTR
Query on PTR
A,
C,
G [auth R],
I [auth T]
L-PEPTIDE LINKINGC9 H12 N O6 PTYR
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.15 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.215
  • R-Value Observed: 0.216
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 90.472α = 90
b = 170.211β = 102.75
c = 124.579γ = 90
Software Package:
Software NamePurpose
Aimlessdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-12-16
    Type: Initial release
  • Version 1.1: 2024-11-20
    Changes: Advisory, Data collection, Database references, Derived calculations, Structure summary
