5QXV | pdb_00005qxv

PanDDA analysis group deposition -- Crystal Structure of ATAD2 in complex with PC631

PDB DOI: https://doi.org/10.2210/pdb5QXV/pdb
Deposition Group: G_1002118 (changed state) ExploreG_1002118

Classification: HYDROLASE/HYDROLASE INHIBITOR
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2020-02-11 Released: 2020-04-08
Deposition Author(s): Snee, M., Talon, R., Fowley, D., Collins, P., Nelson, A., Arrowsmith, C.H., Bountra, C., Edwards, A., Von-Delft, F.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.74 Å
R-Value Free:
0.198 (Depositor), 0.220 (DCC)
R-Value Work:
0.172 (Depositor), 0.200 (DCC)
R-Value Observed:
0.173 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

PanDDA analysis group deposition - Bromodomain of human ATAD2 fragment screening

Snee, M., Talon, R., Fowley, D., Collins, P., Nelson, A., Arrowsmith, C.H., Bountra, C., Edwards, A., Von-Delft, F.

To be published.

Macromolecule Content

Total Structure Weight: 16.15 kDa
Atom Count: 1,482
Modelled Residue Count: 130
Deposited Residue Count: 130
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ATPase family AAA domain-containing protein 2	A	130	Homo sapiens	Mutation(s): 0 Gene Names: ATAD2, L16, PRO2000 EC: 3.6.1.3 (PDB Primary Data), 3.6.1 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q6PL18 (Homo sapiens) Explore Q6PL18 Go to UniProtKB: Q6PL18
PHAROS: Q6PL18 GTEx: ENSG00000156802
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q6PL18
Sequence Annotations Expand
Reference Sequence LOADING

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
RJG (Subject of Investigation/LOI) Query on RJG Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	(3aR,10R,10aR,11aR)-1,2,3,5,10,10a,11,11a-octahydro-3a,10-ethanopyrrolo[3',4':4,5]pyrrolo[1,2-b]isoquinolin-13-one C₁₆ H₁₈ N₂ O JTERCRHEKKZOFH-MEWXFMAXSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A]	C [auth A], D [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain C [auth A] Focus chain D [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A]	E [auth A], F [auth A], G [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A]
