6ZTW

Crystal Structure of catalase HPII from Escherichia coli (serendipitously crystallized)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.84 Å
  • R-Value Free: 0.184
  • R-Value Work: 0.144
  • R-Value Observed: 0.144

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.5 of the entry. See complete history


Literature

Serendipitous crystallization of E. coli HPII catalase, a sequel to "the tale usually not told".

Grzechowiak, M.Sekula, B.Jaskolski, M.Ruszkowski, M.

(2021) Acta Biochim Pol 68: 29-31

  • DOI: https://doi.org/10.18388/abp.2020_5501
  • Primary Citation of Related Structures:
    6ZTV, 6ZTW, 6ZTX

  • PubMed Abstract:

    Protein crystallographers are well aware of the trap of crystallizing E. coli proteins instead of the macromolecule of interest if heterologous recombinant protein expression in E. coli was part of the experimental pipeline. Among the well-known culprits are YodA metal-binding lipocalin (25 kDa) and YadF carbonic anhydrase (a tetramer of 25 kDa subunits). We report a novel crystal form of another such culprit, E. coli HPII catalase, which is a tetrameric protein of ~340 kDa molecular weight. HPII is likely to contaminate recombinant protein samples, co-purify, and then co-crystallize with the target proteins, especially if their masses in size exclusion chromatography are ~300-400 kDa. What makes this case more interesting but also parlous, is the fact that HPII can crystallize from very low concentrations, even well below 1 mg/mL.


  • Organizational Affiliation

    Institute of Bioorganic Chemistry, Polish Academy of Sciences, Poznań, Poland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Catalase HPII
A, B, C, D, E
A, B, C, D, E, F, G, H
753Escherichia coli K-12Mutation(s): 1
EC: 1.11.1.6
UniProt
Find proteins for P21179 (Escherichia coli (strain K12))
Go to UniProtKB:  P21179
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
HDD (Subject of Investigation/LOI)
Query on HDD

Download Ideal Coordinates CCD File
EA [auth F]
I [auth A]
IA [auth G]
LA [auth H]
M [auth B]
EA [auth F],
I [auth A],
IA [auth G],
LA [auth H],
M [auth B],
S [auth C],
X [auth D],
Z [auth E]
CIS-HEME D HYDROXYCHLORIN GAMMA-SPIROLACTONE
C34 H32 Fe N4 O5
UMGOPAWIGKFTRK-QQDQPIDJSA-N
TRS
Query on TRS

Download Ideal Coordinates CCD File
AA [auth E]
BA [auth E]
FA [auth F]
J [auth A]
JA [auth G]
AA [auth E],
BA [auth E],
FA [auth F],
J [auth A],
JA [auth G],
MA [auth H],
N [auth B],
T [auth C],
Y [auth D]
2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL
C4 H12 N O3
LENZDBCJOHFCAS-UHFFFAOYSA-O
MPD
Query on MPD

Download Ideal Coordinates CCD File
O [auth B](4S)-2-METHYL-2,4-PENTANEDIOL
C6 H14 O2
SVTBMSDMJJWYQN-YFKPBYRVSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
DA [auth E]
K [auth A]
KA [auth G]
L [auth A]
R [auth B]
DA [auth E],
K [auth A],
KA [auth G],
L [auth A],
R [auth B],
W [auth C]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
EDO
Query on EDO

Download Ideal Coordinates CCD File
CA [auth E]
GA [auth F]
HA [auth F]
P [auth B]
Q [auth B]
CA [auth E],
GA [auth F],
HA [auth F],
P [auth B],
Q [auth B],
U [auth C],
V [auth C]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
OCS
Query on OCS
A, B, C, D, E
A, B, C, D, E, F, G, H
L-PEPTIDE LINKINGC3 H7 N O5 SCYS
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.84 Å
  • R-Value Free: 0.184
  • R-Value Work: 0.144
  • R-Value Observed: 0.144
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 121.188α = 90
b = 168.071β = 105.239
c = 137.982γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Polish National Science CentrePolandSONATA 2018/31/D/NZ1/03630
Polish National Science CentrePolandSYMFONIA 2016/20/W/ST5/00478
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesIntramural Research Program

Revision History  (Full details and data files)

  • Version 1.0: 2020-10-07
    Type: Initial release
  • Version 1.1: 2021-02-10
    Changes: Database references
  • Version 1.2: 2021-02-24
    Changes: Database references
  • Version 1.3: 2021-03-03
    Changes: Database references
  • Version 1.4: 2021-03-31
    Changes: Database references
  • Version 1.5: 2024-01-31
    Changes: Data collection, Database references, Refinement description
