RCSB PDB - 8K50: Crystal structure of HLA-A*11:01 in complex with KRAS G12V peptide (VVVGARGVGK)

 8K50

Crystal structure of HLA-A*11:01 in complex with KRAS G12V peptide (VVVGARGVGK)

  • Classification: IMMUNE SYSTEM
  • Organism(s): Homo sapiens
  • Expression System: Escherichia coli
  • Mutation(s): Yes

  • Deposited: 2023-07-20 Released: 2025-01-29
  • Deposition Author(s): Xu, K.
  • Funding Organization(s): Ministry of Science and Technology (MoST, China)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.281
  • R-Value Work: 0.223
  • R-Value Observed: 0.225

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Crystal structure of HLA-A*11:01 in complex with KRAS G12R peptide (VVVGARGVGK)

Xu, Y.

To be published.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
HLA class I histocompatibility antigen, A alpha chain
A, D, G, J
276Homo sapiensMutation(s): 3
Gene Names: HLA-AHLAA
UniProt & NIH Common Fund Data Resources
Find proteins for P04439 (Homo sapiens)
Explore P04439
Go to UniProtKB:  P04439
PHAROS:  P04439
GTEx:  ENSG00000206503
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04439
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Beta-2-microglobulin
B, E, H, K
122Homo sapiensMutation(s): 0
Gene Names: B2MCDABP0092HDCMA22P
UniProt & NIH Common Fund Data Resources
Find proteins for P61769 (Homo sapiens)
Explore P61769
Go to UniProtKB:  P61769
PHAROS:  P61769
GTEx:  ENSG00000166710
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP61769
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
KRAS G12V peptide (VVVGAVGVGK)
C, F, I, L
10Homo sapiensMutation(s): 1
Gene Names: KRASKRAS2RASK2
EC: 3.6.5.2
UniProt & NIH Common Fund Data Resources
Find proteins for P01116 (Homo sapiens)
Explore P01116
Go to UniProtKB:  P01116
PHAROS:  P01116
GTEx:  ENSG00000133703
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01116
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.281
  • R-Value Work: 0.223
  • R-Value Observed: 0.225
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 116.289α = 90
b = 121.845β = 90
c = 133.376γ = 90
Software Package:
Software NamePurpose
PHENIXphasing
PHENIXrefinement
Cootmodel building
XDSdata reduction

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data

  • Released Date: 2025-01-29
  • Deposition Author(s): Xu, K.

Funding OrganizationLocationGrant Number
Ministry of Science and Technology (MoST, China)China2021YFA1302200

Revision History  (Full details and data files)

  • Version 1.0: 2025-01-29
    Type: Initial release
