9OFZ | pdb_00009ofz

GluN1/GluN3A in complex with glycine, TMD focused, in desensitized conformation

PDB DOI: https://doi.org/10.2210/pdb9OFZ/pdb
EM Map EMD-70447: EMDB EMDataResource

Classification: TRANSPORT PROTEIN
Organism(s): Rattus norvegicus
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2025-04-30 Released: 2026-08-26
Deposition Author(s): Kim, J., Gouaux, E.
Funding Organization(s): National Institutes of Health/National Institute of Neurological Disorders and Stroke (NIH/NINDS)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 4.51 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9OFZ

This is version 1.0 of the entry. See complete history.

Literature

GluN1/GluN3A in complex with glycine, TMD focused, in desensitized conformation

Kim, J., Gouaux, E.

To be published.

Macromolecule Content

Total Structure Weight: 412.31 kDa
Atom Count: 2,667
Modeled Residue Count: 449
Deposited Residue Count: 3,680
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Isoform E of Glutamate receptor ionotropic, NMDA 1	A, B [auth C]	870	Rattus norvegicus	Mutation(s): 0 Gene Names: Grin1, Nmdar1
UniProt
Find proteins for P35439 (Rattus norvegicus) Go to UniProtKB: P35439
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P35439-5
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Glutamate receptor ionotropic, NMDA 3A	C [auth B], D	970	Rattus norvegicus	Mutation(s): 0 Gene Names: Grin3a
UniProt
Find proteins for Q9R1M7 (Rattus norvegicus) Explore Q9R1M7 Go to UniProtKB: Q9R1M7
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9R1M7
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 4.51 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.20.1_4487
RECONSTRUCTION	cryoSPARC	4.4

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-08-26

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of Neurological Disorders and Stroke (NIH/NINDS)	United States	--

Revision History (Full details and data files)

Version 1.0: 2026-08-26
Type: Initial release
