AF_AFB5YPZ9F1

COMPUTED STRUCTURE MODEL OF VITAMIN B12 IMPORT SYSTEM PERMEASE PROTEIN BTUC

There are no experimental data to verify the accuracy of this computed structure model. See Model Confidence metrics below for all regions of the polypeptide chain.

• AlphaFold DB: AF-B5YPZ9-F1
• Released in AlphaFold DB:  2021-12-09
  Last Modified in AlphaFold DB: 2022-09-30
• Organism(s): Escherichia coli O157:H7 str. EC4115
• UniProtKB: B5YPZ9

---

Model Confidence

• pLDDT (global): 91.8
• pLDDT (local):

Model Confidence

•   Very high (pLDDT > 90)
•   Confident (70 < pLDDT ≤ 90)
•   Low (50 < pLDDT ≤ 70)
•   Very low (pLDDT ≤ 50)

Computed Structure Models provide per-residue confidence score (pLDDT) between 0 and 100. Some regions below 50 pLDDT may be unstructured in isolation.

Assembly

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Macromolecule Content

• Total Structure Weight: 34.96 kDa
• Atom Count: 2,455
• Modeled Residue Count: 326
• Deposited Residue Count: 326
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Vitamin B12 import system permease protein BtuC	A	326	Escherichia coli O157:H7 str. EC4115	Mutation(s): 0  Gene Names: btuC
UniProt
Find proteins for B5YPZ9 (Escherichia coli O157:H7 (strain EC4115 / EHEC)) Explore B5YPZ9  Go to UniProtKB:  B5YPZ9
