3UNB

Mouse constitutive 20S proteasome in complex with PR-957


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.230
  • R-Value Observed: 0.232

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.6 of the entry. See complete history


Literature

Immuno- and constitutive proteasome crystal structures reveal differences in substrate and inhibitor specificity.

Huber, E.M.Basler, M.Schwab, R.Heinemeyer, W.Kirk, C.J.Groettrup, M.Groll, M.

(2012) Cell 148: 727-738

  • DOI: https://doi.org/10.1016/j.cell.2011.12.030
  • Primary Citation of Related Structures:
    3UN4, 3UN8, 3UNB, 3UNE, 3UNF, 3UNH

  • PubMed Abstract:

    Constitutive proteasomes and immunoproteasomes shape the peptide repertoire presented by major histocompatibility complex class I (MHC-I) molecules by harboring different sets of catalytically active subunits. Here, we present the crystal structures of constitutive proteasomes and immunoproteasomes from mouse in the presence and absence of the epoxyketone inhibitor PR-957 (ONX 0914) at 2.9 Å resolution. Based on our X-ray data, we propose a unique catalytic feature for the immunoproteasome subunit β5i/LMP7. Comparison of ligand-free and ligand-bound proteasomes reveals conformational changes in the S1 pocket of β5c/X but not β5i, thereby explaining the selectivity of PR-957 for β5i. Time-resolved structures of yeast proteasome:PR-957 complexes indicate that ligand docking to the active site occurs only via the reactive head group and the P1 side chain. Together, our results support structure-guided design of inhibitory lead structures selective for immunoproteasomes that are linked to cytokine production and diseases like cancer and autoimmune disorders.


  • Organizational Affiliation

    Center for Integrated Protein Science at the Department Chemie, Lehrstuhl für Biochemie, Technische Universität München, Garching D-85747, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-2A,
CA [auth c],
O,
QA [auth q]
234Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for P49722 (Mus musculus)
Explore P49722
Go to UniProtKB:  P49722
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP49722
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-4B,
DA [auth d],
P,
RA [auth r]
261Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for Q9R1P0 (Mus musculus)
Explore Q9R1P0
Go to UniProtKB:  Q9R1P0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9R1P0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-7C,
EA [auth e],
Q,
SA [auth s]
248Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for Q9Z2U0 (Mus musculus)
Explore Q9Z2U0
Go to UniProtKB:  Q9Z2U0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9Z2U0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-5D,
FA [auth f],
R,
TA [auth t]
241Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for Q9Z2U1 (Mus musculus)
Explore Q9Z2U1
Go to UniProtKB:  Q9Z2U1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9Z2U1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-1E,
GA [auth g],
S,
UA [auth u]
263Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for Q9R1P4 (Mus musculus)
Explore Q9R1P4
Go to UniProtKB:  Q9R1P4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9R1P4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-3F,
HA [auth h],
T,
VA [auth v]
255Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for O70435 (Mus musculus)
Explore O70435
Go to UniProtKB:  O70435
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO70435
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit alpha type-6G,
IA [auth i],
U,
WA [auth w]
246Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for Q9QUM9 (Mus musculus)
Explore Q9QUM9
Go to UniProtKB:  Q9QUM9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9QUM9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-7H,
JA [auth j],
V,
XA [auth x]
234Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for P70195 (Mus musculus)
Explore P70195
Go to UniProtKB:  P70195
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP70195
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-3I,
KA [auth k],
W,
YA [auth y]
205Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for Q9R1P1 (Mus musculus)
Explore Q9R1P1
Go to UniProtKB:  Q9R1P1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9R1P1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-2J,
LA [auth l],
X,
ZA [auth z]
201Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for Q9R1P3 (Mus musculus)
Explore Q9R1P3
Go to UniProtKB:  Q9R1P3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9R1P3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-5AB [auth 1],
K,
MA [auth m],
Y
205Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for O55234 (Mus musculus)
Explore O55234
Go to UniProtKB:  O55234
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO55234
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-1BB [auth 2],
L,
NA [auth n],
Z
213Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for O09061 (Mus musculus)
Explore O09061
Go to UniProtKB:  O09061
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO09061
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-4AA [auth a],
CB [auth 3],
M,
OA [auth o]
219Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for P99026 (Mus musculus)
Explore P99026
Go to UniProtKB:  P99026
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP99026
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
Proteasome subunit beta type-6BA [auth b],
DB [auth 4],
N,
PA [auth p]
205Mus musculusMutation(s): 0
EC: 3.4.25.1
UniProt
Find proteins for Q60692 (Mus musculus)
Explore Q60692
Go to UniProtKB:  Q60692
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ60692
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
04C
Query on 04C

Download Ideal Coordinates CCD File
EB [auth H]
FB [auth K]
GB [auth N]
HB [auth V]
IB [auth Y]
EB [auth H],
FB [auth K],
GB [auth N],
HB [auth V],
IB [auth Y],
JB [auth b],
KB [auth j],
LB [auth m],
MB [auth p],
NB [auth x],
OB [auth 1],
PB [auth 4]
1,2,4-trideoxy-4-methyl-2-{[N-(morpholin-4-ylacetyl)-L-alanyl-O-methyl-L-tyrosyl]amino}-1-phenyl-D-xylitol
C31 H44 N4 O7
SLVOSRJOLWNALP-QAKIEGLASA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.230
  • R-Value Observed: 0.232
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 171.72α = 90
b = 198.59β = 106.59
c = 226.75γ = 90
Software Package:
Software NamePurpose
XDSdata scaling
PHASERphasing
REFMACrefinement
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-02-29
    Type: Initial release
  • Version 1.1: 2012-03-28
    Changes: Database references
  • Version 1.2: 2012-12-12
    Changes: Other
  • Version 1.3: 2013-11-13
    Changes: Structure summary
  • Version 1.4: 2013-11-20
    Changes: Structure summary
  • Version 1.5: 2023-09-13
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.6: 2024-11-27
    Changes: Structure summary
