3VBL

Crystal Structure of the S84C mutant of AntD, an N-acyltransferase from Bacillus cereus in complex with dTDP-4-amino-4,6-dideoxyglucose and Coenzyme A


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.170
  • R-Value Observed: 0.173

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Structural Studies of AntD: An N-Acyltransferase Involved in the Biosynthesis of d-Anthrose.

Kubiak, R.L.Holden, H.M.

(2012) Biochemistry 51: 867-878

  • DOI: https://doi.org/10.1021/bi201650c
  • Primary Citation of Related Structures:
    3VBI, 3VBJ, 3VBK, 3VBL, 3VBM, 3VBN, 3VBP

  • PubMed Abstract:

    The unusual dideoxy sugar d-anthrose has been identified as an important component in the endospores of infectious agents such as Bacillus anthracis and Bacillus cereus. Specifically, it is the terminal sugar on the bacterium's exosporium, and it provides a point of interaction between the spore and the host. The biosynthesis of d-anthrose involves numerous steps starting from α-d-glucose 1-phosphate. Here we present a combined structural and functional investigation of AntD from B. cereus. This enzyme plays a key role in d-anthrose biosynthesis by catalyzing the acylation of the C-4″ amino group of dTDP-4-amino-4,6-dideoxyglucose using 3-hydroxy-3-methylbutyryl-CoA as the acyl donor. For this investigation, two ternary complexes of AntD were determined to 1.8 Å resolution: one in which the protein contained bound β-hydroxybutyryl-CoA and dTDP and the second with CoA and dTDP-4-amino-4,6-dideoxyglucose. On the basis of these high-resolution structures, it was shown that the side chain of Asp 94 lies within hydrogen bonding distance of the sugar C-4″ amino group, and the side chain of Ser 84 resides near the carbonyl oxygen of β-hydroxybutyryl-CoA. To test the roles of these residues in the catalytic mechanism of AntD, various site-directed mutant proteins were prepared and subjected to kinetic and structural analyses. The D94A and D94N mutant proteins demonstrated enzymatic activity, albeit with significantly reduced catalytic efficiencies. The S84A mutant protein showed an approximate 10-fold decrease in activity. Interestingly, the S84C and S84T mutant proteins were both active but demonstrated substrate inhibition. The three-dimensional structures of all of the mutant proteins were nearly identical to that of the wild-type enzyme, indicating that the changes in their kinetic parameters were not due to major conformational changes. Taken together, these data suggest that Asp 94 is important for substrate binding, but probably does not function as an enzymatic base, and that Ser 84 most likely plays a role in the formation of an oxyanion hole.


  • Organizational Affiliation

    Department of Biochemistry, University of Wisconsin, Madison, Wisconsin 53706, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Galactoside O-acetyltransferaseA,
B [auth C],
C [auth E]
205Bacillus cereus SJ1Mutation(s): 1
Gene Names: antdBCSJ1_02085
EC: 2.3.1.18
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
COA
Query on COA

Download Ideal Coordinates CCD File
D [auth A],
H [auth C],
K [auth E]
COENZYME A
C21 H36 N7 O16 P3 S
RGJOEKWQDUBAIZ-IBOSZNHHSA-N
0FX
Query on 0FX

Download Ideal Coordinates CCD File
F [auth A],
I [auth C],
L [auth E]
dTDP-4-amino-4,6-dideoxyglucose
C16 H27 N3 O14 P2
UIVJXHWSIFBBCY-LPGAPTBISA-N
BCT
Query on BCT

Download Ideal Coordinates CCD File
G [auth A],
J [auth C],
M [auth E]
BICARBONATE ION
C H O3
BVKZGUZCCUSVTD-UHFFFAOYSA-M
CL
Query on CL

Download Ideal Coordinates CCD File
E [auth A]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.170
  • R-Value Observed: 0.173
  • Space Group: P 41
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 70.749α = 90
b = 70.749β = 90
c = 138.692γ = 90
Software Package:
Software NamePurpose
PROTEUM PLUSdata collection
PHASERphasing
REFMACrefinement
SAINTdata reduction
SADABSdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-01-25
    Type: Initial release
  • Version 1.1: 2012-02-22
    Changes: Database references
  • Version 1.2: 2024-04-03
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.3: 2024-11-27
    Changes: Structure summary
